High Speed Slip rings

Number of Circuits: 4CKT
Insulation Resistance: ≥1000MΩ@1000VDC
Voltage: 450V

JINPAT Slip Pings, connecting infinite possibilities.

Specialized in rotary transmission for 30 years +, stable and reliable for every revolution.

Features

1、High reliability

2、Long service life

3、Wide selection range of aperture

4、Maintenance free

Advantages

1、Up to 20 channels

2、Maximum aperture 80mm

3、Maximum speed 10000rpm

4、Life not less than 50 million revolutions

5、If the above parameters are exceeded, customization can be discussed with the engineering team.

Electronic & Electric			Mechanical
Circuits	Total	4 CKT	Working Speed	6000rpm (Ultimate speed 10000rpm)
	Detail	4*1A	Inner Diameter	/
Rating Voltage		450V	Contact Material	Gold to gold
Dielectric Strength		Between two routes≥1000VAC@50Hz	Shell Material	Aluminum alloy stainless steel
Insulation Resistance		≥1000MΩ@1000VDC	Lead Wire Length	Stator:500mm Rotor:500mm
Environment			Remarks
Working Temperature		-10°C~+60°C	Application	/
Working Humidity		≤60%RH	Other	/
IP		/	/

High speed test instrument slip ring

Number of Circuits: 4CKT
Insulation Resistance: ≥1000MΩ@1000VDC
Voltage: 450V

Aero engine test equipment high speed slip ring

Number of Circuits: 4CKT
Insulation Resistance: ≥1000MΩ@1000VDC
Voltage: 450V

Detect propeller slip rings

Number of Circuits: 4CKT
Insulation Resistance: ≥1000MΩ@1000VDC
Voltage: 450V
