High-Frequency Phase-Stable Low-Loss Coaxial Cables, along with their auxiliary counterparts, deliver exceptional RF performance in aerospace, electromagnetic defense, anechoic chamber setups, and modern 5G applications.
| Product specification | |||
| Interface Type | BNC-M/BNC-M(75Ω) | Body Materials | BRASS/PTFE |
| Frequency range | DC-3GHz | Plating | GOLD/NICKEL |
| VSWR,Max | 1.5 | Durability | ＞500cycles |
| Insertion loss,Max | 2.8dB | Temperature range | ﹣40~+85°C |
| Voltage rating | 170V(rms) | RoHS 2002/95/EC | RoHS compliant |
| Dielectric withstanding voltage | 250V | Cable retention force | ＞2lbs |
| Insulation resistance | 1000MΩ | Min.bending radius，repeated | 14mm |
BNC-M-BNC-M-RF1.32-500mm Typical High Frequency Auxiliaries
