The LPP rotary unions can perform rotation of 360 degrees. The medium includes inert gas such as compressed air, steam, vacuum, nitrogen, hydrogen, etc. It can integrate slip ring to transport various control signals. The sealing surface and sealing ring are made of special materials, with the advantages of wear resistance, long life, corrosion resistance, and no leakage. Customers can install LPP rotary unions independently according to the application environment.
Features:
◎Continuable medium: compressed air, nitrogen, and other inert gases;
◎Small size, light weight, low torque
◎Integrated power, switching signal, Ethernet, USB, industrial bus, sensor and other signals;
◎Customized rotary joint parameters and integrated slip ring can be customized according to customer requirements;
◎The joint and pipe diameter can be customized according to customer requirements;
Optional
◎Inner diameter & Outer diameter/Number of circuits/Current & Voltage/Wire length/Housing material and color/Protection level/Signal and power can be transmitted separately or in combination
| Model Code | Passages(Gas/Flow) | Medium Type | Size | Joint thread | Flow Orifice |
|---|---|---|---|---|---|
| LPPA-LM0101 | 1 in 1 out | Air, Vacuum | Φ40*Φ6*41 | M5 | Φ3 |
| LPPA-LM0201 | 2 in 2 out | Air, Vacuum | Φ40*Φ6*50 | M5 | Φ3 |
| LPPA-LM0401 | 4 in 4 out | Air, Vacuum | Φ40*Φ6*68 | M5 | Φ3 |
| LPPA-LM0601 | 6 in 6 out | Air, Vacuum | Φ40*Φ6*86 | M5 | Φ3 |
| LPPA-LM0801 | 8 in 8 out | Air, Vacuum | Φ40*Φ6*104 | M5 | Φ3 |
| LPPA-LM1001 | 10 in 10 out | Air, Vacuum | Φ40*Φ6*123 | M5 | Φ3 |
| LPPA-LM01201 | 12 in 12 out | Air, Vacuum | Φ40*Φ6*156 | M5 | Φ3 |
| LPPA-LM01601 | 16 in 16 out | Air, Vacuum | Φ40*Φ6*201 | M5 | Φ3 |
| LPPA-LM02401 | 24 in 24 out | Air, Vacuum | Φ40*Φ6*307 | M5 | Φ3 |
